Diamond Audio - DXM1200.1D

DXM Series Monoblock 1200W RMS Class D Waterproof Amplifier

All-weather amplifier for your OUTDOOR life (IPX67 Rated)

• Power @ 1Ω: 1200W RMS
• Power @ 2Ω: 800W RMS
• Power @ 4Ω: 500W RMS
• Total Harmonic Distortion: <0.3%
• S/N Ratio (1W@4Ω): >-102dB
• Gain Range: 0.2v-10v
• Crossover Range: 40Hz-250Hz
• Frequency Range: 40Hz-300Hz
• Sub Sonic: 10Hz-55Hz
• Bass Boost: 0dB-18dB
• Current Draw Full Power (Music): 140A (14A) AVG
• Fuse Rating: 70A
• Dimensions: 11.8”x4.3”x1.7” (298.6mm x 110mm x 44.0mm)

Features

• Power & Protection Led Light Status Indicator
• Short Circuit, Thermal and Voltage Protection
• Selectable Phase: 0°-180°
• IPX67 Rated
• Remote Bass Knob Included
